Homework 2: Getting Comfortable with libembroidery and the Turtle Class

Our overall goal in this assignment is to make a program that creates embroidery patches can can be sewn out on the embroidery machines in the Maker Space. In this part of the assignment, you will familiarize yourself with the C++ Turtle class, which is a CS 70-specific wrapper to libembroidery, a C library that generates embroidery pattern files.

The Turtle Class

The Turtle class is a CS 70-specific wrapper to libembroidery, a C library that generates embroidery pattern files. This class provides an interface very similar to the Python Turtle that you may have seen previously (e.g., in CS 5).

Any file that uses the Turtle class requires you to add the line

#include <cs70/turtle.hpp>

to the top of the file so that the C++ compiler will get all the declarations it needs.

The functions you write this week will work with a Turtle object. You can declare and initialize a (default) Turtle in a variable t by writing:

Turtle t;

You can call a function on a Turtle using the familiar dot notation:

t.penup();

Here's the full set of member functions available for your Turtle (which you might want to keep open in another tab as you work):

• Turtle Class Specification

Your Task, Part 1: Creating a Skeleton

In this part of the assignment you will create the files needed for the assignment. Your goal is to have code that can compile and run, even if it doesn't do anything yet.

Required Files

Your code for this week will be split into three files:

• embroidery.hpp will declare all of the functions that you write.
  • We'll tell you what functions to declare below.
• embroidery.cpp will define all of the functions that you write.
  • We'll just make placeholders for the functions you will write later.
• maker.cpp will define the main function that uses the functions you write in embroidery.cpp.
  • We’ve provided maker.cpp for you, but you will need to edit it to uncomment calls to each of the functions as you finish writing them.

Creating the Header File, embroidery.hpp

Create the file embroidery.hpp in your embroidery/ directory. Since it's a header file, you should begin by creating an include guard (covered in Week 3, Lesson 1).

Once you've done that, add the line

#include <cs70/turtle.hpp>

as the first code line after the include guard. This line will allow us to refer to the Turtle class in our function declarations.

Your header file also needs to declare all of the functions that you are going to write this week:

void rect(Turtle& t, float width, float height);

void meetTurtle();

void plotExampleData();

void plotStudentData();

Although C++ itself would be happy if you just copied and pasted the above code into your embroidery.hpp file, doing so isn't sufficient for this assignment because header files are often read by humans as well as by the compiler. The header file specifies the interface to your code, so it should be easy for a human reader to understand what each function does, what its parameters are, and what it returns (if anything).

To meet those requirements, you'll need to add comments to your code.

The help page on commenting includes information on how to document the interface of your functions. Click the button below to open it in a new tab:

• CS 70 Commenting Guide

Creating the Implementation File, embroidery.cpp

Now that you've made the header file, you need to create the corresponding implementation file, embroidery.cpp, in your embroidery/ directory.

Your implementation file should #include your interface header file at the top:

#include "embroidery.hpp"

Next, you need to define all of the functions you are going to write this week. For now, your implementations can be blank placeholders (a.k.a. stubs). We call this rudimentary version of the file a stub file.

#include <stdexcept>  // for std::logic_error

void rect(Turtle& /* t */, float /* width */, float /* height */) {
    // ^-- variable names commented out to prevent "unused variable" warnings
    //     in this stub.
    // FIXME: Uncomment variable names when stub is implemented.
    throw std::logic_error("Not implemented (yet!)");  // FIXME: Implement it!
}

void meetTurtle() {
    throw std::logic_error("Not implemented (yet!)");  // FIXME: Implement it!
}

void plotExampleData() {
    throw std::logic_error("Not implemented (yet!)");  // FIXME: Implement it!
}

void plotStudentData() {
    throw std::logic_error("Not implemented (yet!)");  // FIXME: Implement it!
}

Compiling the Program

At this point, your program doesn't really do anything, but it should still be possible to compile and link it all. Go ahead and try!

Note that you will also need to tell the linker that you are using functions from the turtle, point, and libembroidery libraries:

clang++ -gdwarf-4 -c -std=c++17 -Wall -Wextra -pedantic embroidery.cpp
clang++ -gdwarf-4 -c -std=c++17 -Wall -Wextra -pedantic maker.cpp
clang++ -lembroidery -lturtle -lpoint maker.o embroidery.o -o maker

Running the Program

At this point, you should be able to run your program by typing ./maker at the command line. You should see something like

embroidery SERVER > ./maker
terminate called after throwing an instance of 'std::logic_error'
  what():  Not implemented (yet!)
[1]    131345 IOT instruction (core dumped)  ./maker

The program will crash because the functions you are calling haven't been implemented yet, but at least you know that everything is set up correctly!

Your Task, Part 2: Writing Functions

Now that we have a skeleton that compiles and runs, we can start filling in the functions.

Include Additional Headers

Your embroidery.cpp file will need to include the following additional headers to support the code we're going to write:

#include <iostream>
#include <fstream>
#include <string>
#include <cstddef>
#include <cs70/turtle.hpp>

You should add them now so that you don’t run into problems later.

using namespace std;

Writing Your First Turtle Functions

You'll write two functions for this part of the assignment.

The rect Function

The first function you will write is rect. You've already declared it in embroidery.hpp and documented it there with comments (hopefully!), and written a stub in embroidery.cpp. Now it's time to implement it!

In order to write your rect function, you will need to consult the Turtle Class Specification to decide which functions are useful for this task. For example, to tell a Turtle t to put the pen down, you would call t.pendown(). Some notes for drawing the rectangle:

• Assume that the turtle starts at the bottom-left corner of the rectangle it will be drawing and is facing in the direction of the desired horizontal base of the rectangle.
• The position with coordinates (x+100, y+50) is 100 units to the right and 50 units up from (x,y).
• Depending on which functions you use to move the Turtle, you may not need to set direction or turn the Turtle.

The meetTurtle Function

The next function you will write is meetTurtle, by replacing the stub in embroidery.cpp with a real implementation. This function should start by declaring the following constants:

    // Patch size in embroidery units: the rectangular area we draw into.
    constexpr float PATCH_WIDTH = 50;   // overall patch width
    constexpr float PATCH_HEIGHT = 40;  // overall patch height

    // Stitch sizes: when satin is off these control spacing between stitches;
    // when satin is on the step size controls the satin stitch "width".
    constexpr int EDGE_STITCH_SIZE = 2;  // coarser stitches for the border
    constexpr int TEXT_STITCH_SIZE = 1;  // finer stitches for text detail

    // Visual scaling values for text and satin mode:
    constexpr float FONT_SIZE = 1.0;  // scale passed to displayMessage()
    // Satin 'delta' controls forward step between side-to-side stitches in
    // satin mode.
    constexpr float SATIN_DELTA = 0.3;

Your code should then do the following:

• Create a Turtle object
  • We covered how to do that in the section on the Turtle class above.
• Draw a satin-stitched rectangle that is PATCH_WIDTH wide, PATCH_HEIGHT tall, and has a step size of EDGE_STITCH_SIZE. Be sure to use your rect function!
• Add three lines of satin-stitched text inside the rectangle that have a size of TEXT_STITCH_SIZE and a text scale FONT_SIZE:
  • The initials of partner one in your group
  • A team name (choose something relatively short, so it will fit on your patch!)
  • The initials of partner two in your group
• Call the Turtle’s end() function to finish the embroidery pattern
• Save the results to a file called meet_turtle.dst

Compiling and Running Your Code

You can use the same commands as before to compile and link your code. When you run your program, a file called meet_turtle.dst will be created. In the section below, we describe how to convert that file into a format you can view.

Viewing the Results

The file our Turtle will create is a .dst format file, which is readable by the embroidery machines in the Maker Space. To make it easier to test your code as you work, the server includes a command-line tool called embconv that will turn .dst files into .svg image files.

To use embconv, give it the name of your embroidery file and the name of the output image file:

embconv meet_turtle.dst meet_turtle.svg

VS Code should allow you to view the file if you open it from the File Explorer pane (i.e., double-click the filename). The image isn't a perfect replication of what your image will look like as an embroidery project, but it's close enough to be helpful.

As you work on each of your functions this week, you should regularly write out your Turtle’s output to a .dst file, embconv it to a .svg file, and view it.

If everything works as expected, your final meet_turtle.svg file should look something like

Note that the color on your image might be different than our example—.dst files don’t store color information (the color of the embroidered result depends on the color of thread in the sewing machine), so embconv just picks a random color each time it's run.
